Downlight / YONJA

  • P
  • W
  • C
  • S
  • O
  • G
  • U
  • P

    PRODUCT & POWER OPTIONS

    PRODUCT NAME LIGHT COLOR INPUT VOLTAGE (V) POWER (W) LUMINOUS FLUX (lm) DIMENSIONS (AxB) (mm) WEIGHT (kg)
    YONJA50 WW-NW 220-240V AC 10 850 Ø55x110 0,4
    YONJA85 WW-NW 220-240V AC 20 1.800 Ø90x185 0,5
    YONJA110 WW-NW 220-240V AC 30 2.550 Ø115x200 0,8
    YONJA110 WW-NW 220-240V AC 40 3.200 Ø115x200 0,85

    *Power and Lumen values provided are based off of a "natural white (NW) LED"

    ELECTROMECHANICAL SPECIFICATIONS

    • Electrostatic powder painted aluminium body
    • High efficiency aluminum reflector
    • Compact connection accessories
    • Architectural simple design

  • C

    LIGHT COLOR OPTIONS

    WW:Warm White 3000K
    NW:Natural White 4000K
  • S

    DRIVER OPTIONS

    • 01: Standart Driver
    • 06: *DALI Driver
    • 11: *Driver + Emergency Lighting Kit 1h
    • 12: *Driver + Emergency Lighting Kit 3h
    *Suitable for Yonja85 and Yonja110
  • O

    LENS OPTIONS

    • N: Narrow Angle
    • M: Medium Angle
    • W: Wide Angle
    *W option suitable for Yonja110
  • G

    HOUSING COLOR OPTIONS

    • RAL9005
    • RAL9016
  • U

    UPPER PIECES OPTIONS

    • 35: Black Reflector
    • 36: light Diffuser
      Honeycomb
    *Products with black reflector
  • CONTROL SYSTEM OPTIONS

    Color Type PWM INW PWM DMX DALI 0 - 10V DC TRIAC
    WW-NW-CW
    R,G,B,A
    RGB
    RGBA/W
    RGB DMX
    WHITE DMX
  •  PRODUCT DIAGRAMS
    YONJA YONJA
  • c4.svg
  • c7.svg
  • c35.svg
  • c14.svg
  • c13.svg
  • b2.svg
  • b6.svg
  • b4.svg
  • b7.svg
  • b8.svg
