LED Projector / WH ECO

PRODUCT & POWER OPTIONS

Product Name	Light Color	Input Voltage (V)	Power (W)	Luminous Flux (lm)	Product Weight (kg)
WH2320	WW-NW-CW	220-240V AC	250	31.025	13
WH2320	WW-NW-CW	220-240V AC	300	40.635	13

*Power and Lumen values provided are based off of a “cold white (CW) LED”.

ELECTROMECHANICAL SPECIFICATIONS

• Electrostatic powder coated aluminum injection housing
• High cooling capacity body design
• 4 mm polyurethane luminaire glass with casted gland.
• Aluminum injection side covers
• Electrostatic painted DKP / Galvanized mounting feet
• Stainless fittings and clips

C
LIGHT COLOR OPTIONS

WW:Warm White 3000K

NW:Natural White 4000K

CW:Cold White 6500K
S
DRIVER OPTIONS
- 01: Standart (ON/OFF)
- 06: DALI Driver
O
LENS OPTIONS
- N: Narrow Angle
- W: Wide Angle
- XW: Without lens
G
HOUSING COLOR OPTIONS
- RAL9005
- RAL9016
- RAL9007
J
CONNECTIONS OPTIONS
- 01: Cable
- 02: IP socket
