LEDLine / LLI

PRODUCT & POWER OPTIONS

Product Name	Light Color	Input Voltage (V)	Power (W)	Luminous Flux (lm)	Product Weight (kg)
LLI30LED	WW-NW-CW	24V DC	2,4	275	0,3
LLI30LED	WW-NW-CW	24V DC	7,2	680	0,3
LLI30LED	WW-NW-CW	24V DC	12	1040	0,3
LLI45LED	WW-NW-CW	24V DC	10,8	1010	0,3
LLI45LED	WW-NW-CW	24V DC	18	1520	0,3
LLI60LED	WW-NW-CW	24V DC	4,8	550	0,3
LLI60LED	WW-NW-CW	24V DC	14,4	1580	0,3
LLI90LED	WW-NW-CW	24V DC	7,2	815	0,3
LLI180LED	WW-NW-CW	24V DC	14,4	1600	0,3
LLI30LED	RGB	24V DC	7,2	-	0,3
LLI45LED	RGB	24V DC	10,8	-	0,3
LLI60LED	RGB	24V DC	14,4	-	0,3
LLI90LED	RGB	24V DC	21,6	-	0,3
LLICELL20	RGB-CELL	5V DC	7	-	0,3
LLICELL30	RGB-CELL	5V DC	10	-	0,3
LLI60LED	RGB/W	24V DC	14,4	-	0,3
LLI30LED-DMX	RGB-pixel	24V DC	8,4	-	0,3
LLI45LED-DMX	RGB-pixel	24V DC	12,6	-	0,3
LLI30LED-DMX	RGBW/A-pixel	24V DC	8,2	-	0,3

*Power and Lumen values provided are based off of a “cold white (CW) LED”.

ELECTROMECHANICAL SPECIFICATIONS

• Min. 20 micron anodized aluminum extruded profile
• Stainless connectors
• PVC side cover with UV protection
• Transparent or diffused polycarbonate top cover with UV protection
• Cooling capacity up to 21,6 W/m
• Suitable for surface mounting

LIGHT COLOR OPTIONS

WW:Warm White	3000K	R:Red	625nm	RGB
NW:Natural White	4000K	G:Green	525nm	RGBW
CW:Cold White	6500K	B:Blue	465nm	RGBA
		A:Amber	590nm

J
CONNECTIONS OPTIONS
- 01: Cable-Side Outlet
- 02: IP Socket-Side Outlet
- 06: Cable-Bottom outlet
- 07: IP Socket bottom outlet
U
UPPER COVER OPTIONS
- 0: Coverless
  (IP20)
- 01: Diffused
  (IP40)
- 02: Transparent
  (IP40)
I
IP PROTECTION CLASS
EXTERNAL PIXEL CONTROL ACCESSORIES
DMX Power Connector
- E1: Type 1
- E2: Type 2
- E3: Type 3
- E4: Type 4
DMX Power Connector protection box*
- M1: Middle
- M2: Side
- M3: Corner
*Pixel control box and power connector protection box are avaliable for Led Cell only
